The S-1325 AD+ Plus Dual Head CNC Router Machine is a high-performance industrial CNC router engineered to maximize productivity through its advanced dual-head machining system. Designed for furniture manufacturers, sign makers, woodworking industries, and custom fabrication businesses, this machine enables simultaneous machining of identical designs, significantly reducing production time while maintaining exceptional precision.
Built with a heavy-duty steel frame, full servo drive technology, and precision German components, the S-1325 AD+ Plus ensures stable, accurate, and reliable operation even during continuous industrial use. The machine is equipped with dual high-speed air-cooled spindles, making it ideal for large-scale production of doors, furniture panels, decorative carvings, signage, and customized components.
Capable of processing a wide variety of materials, including MDF, plywood, hardwood, acrylic, PVC, ACP sheets, aluminum, brass, copper, marble, granite, and glass, this CNC router is a versatile solution for businesses seeking speed, efficiency, and consistent quality.
Key Features
- Dual-head CNC router for simultaneous machining
- Increases production speed and reduces operating time
- Suitable for continuous industrial production
- High-precision 2D and 3D cutting, carving, engraving, and profiling
- Available working sizes: 8×4 ft, 8×5 ft, and 10×5 ft
- Dual 3.5 kW / 5.5 kW / 6 kW air-cooled spindles (Italian HSD optional)
- Spindle speed up to 24,000 RPM
- Heavy-duty cast steel construction for vibration-free performance
- Taiwan helical rack & pinion transmission for high-speed movement
- TBI precision ball screw Z-axis transmission with brake system
- Full servo motors with planetary gearbox
- High machine accuracy of less than 0.01 mm
- Supports G-Code programming
- Compatible with ArtCAM, AutoCAD, Type3, and other CNC software
- Manual lubrication system for easy maintenance
Applications
- Modular furniture manufacturing
- Wooden door and cabinet production
- Decorative wall panels and partitions
- CNC engraving and relief carving
- Acrylic and ACP signage
- Nameplates and branding solutions
- Interior décor products
- Wooden handicrafts and custom furniture
- Industrial panel machining
- High-volume woodworking production
| Dimensons | Description |
|---|---|
| Working Size | 8 x 4 = 8x5 = 10x5 feet |
| Machine Power | 8 kw or 9.5 hp |
| Z-Transmission | Taiwan 25mm Z Ball Screw Drive with Break System-TBI |
| Table Structure | Cast Steel |
| Bed Structure | T-Slot Alluminium Table with hard pvc |
| Spindle Power | Two Spindle 3.5kw / 5.5kw / 6kw Air Cool HSD Italian / HQD |
| Spindle Speed | 24000 / 18000 RPM |
| Max Air Move Speed | 35000 MM/RPM |
| Max Working Speed | 30000 MM/RPM |
| XY-Transmission | Taiwan 1.25mm Helical Rank Gear XY Axis |
| Guide Rail | LM Guide Rail 20mm Made in Germany |
| Drive | Full Servo Drive |
| Motor | Full Servo Motor with Planetary Gear Box |
| Controller | Rich Auto DSP A11S |
| Main Switch | Omron Made in Germany |
| Electronics | Schneider & Siemens Made in Germany |
| Machine Accuracy | <0.01 mm |
| Inverter | Rituo & Best VDF |
| Program | G-Code Program |
| Voltage | 1 Phase 220AC / 3 Phases 380AC |
| Software | Artcam, Catcam, Autocut |
| Oil Pump | Manual Lubrication System |
| Gross Weight | 1500 kg |
| Accessories | 10 pc. Bits Spanner Full Set Adjustment Feet Screw , Full Set Spindle Nut 1 pc. 2 pc. Sensor, |
