CNC ROUTER MACHINE MODEL S -1325 AD

CNC ROUTER MACHINE MODEL S -1325 AD

Original price was: ₹675,000.00.Current price is: ₹625,000.00.

Category:
Guaranteed Safe Checkout
DescriptionDimension
Working Size1300mm x 2500 x 300mm
Machine Power6 kw or 7.5 hp
Z-TransmissionTaiwan 25mm Z Ball Screw Drive with Break System-TBI
Table StructureCast Steel
Bed StructureT-Slot Alluminium Table with hard pvc
Spindle Power3.7 kw Air Cool HSD Italian
Spindle SpeedAir Cool 18000 RPM/Min Air Cooling
Max Air Move Speed30000 MM/Min
Max Working Speed20000 MM/Min
XY-TransmissionTaiwan 1.25mm Helical Rank Gear XY Axis
Guide RailLM Guide Rail 20mm Made in Germany
DriveStepper / AC Hybrid Servo Motor
MotorStapper / AC Hybrid Servo
ControllerRich Auto DSP A11S
Main SwitchOmron Made in Germany
ElectronicsSchneider & Siemens Made in Germany
Machine Accuracy<0.01 mm
InverterRituo & Best VDF
ProgramG-Code Program
Voltage1 Phase 220AC / 3 Phases 380AC
SoftwareArtcam, Catcam, Autocut
Oil PumpManual Lubrication System
Gross Weight1500 kg
Accessories20 pc. Bits Spanner Full Set Adjustment Feet Screw, Full Set Spindle Nut 1 pc. 2 pc. Sensor, 2 pc. Water Pump
